LED GU10 1-5W 60° | GU10

HX-XF-GU10 60° (X=1,2,3,4,5,6)

Features:
The PBT coated Aluminium GU10 spot light have same function as traditional halogen bulb, but light efficiency 10times more.
Power: 3W, 4W, 5W, 6W
Body: PBT+Aluminium,
Diffuser: Polycarbonate
Aluminium Board: 1.0mm, SOP
LED: Sanan chip, SMD2835
Driver: SMPS IC(BP, PowerTech)
Capacitor: Aishi, Yunxing, Axboom
Base: GU10, G5.3, Nickel-plated Copper
Beam angle: 60°

TOP equivalent

Inquiry

TECHNICAL CHARACTERISTICS

Safety according to-Directive 2014/35/EU(LVD)
EN 62560: 2012+A1:2015+A11:2019
EN 62471: 2008
EN 62473 :2015

EMC according to- Directive 2014/30/EU(EMC)
EN 55015: 2019+A11:2020
EN 61547: 2009,
EN 61000-3-2:2014,
EN 61000-3-3:2013

ERP according to-Directive (EU) 2019/2020 and EEL (EU) 2019/2015

Code	Input	Power	PF	Total Lumen	C.R.I	C.C.T.	Control Mode
LED GU10 60° - 1W
HX-1F-GU10	220-240V	1 W	0.5	100lm	82	3000K	Dim option
HX-1F-GU10	220-240V	1 W	0.5	100lm	82	4000K	Dim option
HX-1F-GU10	220-240V	1 W	0.5	100lm	82	6500K	NDim option

Code	Input	Power	PF	Total Lumen	C.R.I	C.C.T.	Control Mode
LED GU10 60° - 2W
HX-2F-GU10	220-240V	2 W	0.5	180lm	82	3000K	Dim option
HX-2F-GU10	220-240V	2 W	0.5	180lm	82	4000K	Dim option
HX-2F-GU10	220-240V	2 W	0.5	180lm	82	6500K	Dim option

Code	Input	Power	PF	Total Lumen	C.R.I	C.C.T.	Control Mode
LED GU10 60° - 3W
HX-3F-GU10	220-240V	3 W	0.5	270lm	82	3000K	Dim option
HX-3F-GU10	220-240V	3 W	0.5	270lm	82	4000K	Dim option
HX-3F-GU10	220-240V	3 W	0.5	270lm	82	6500K	Dim option

Code	Input	Power	PF	Total Lumen	C.R.I	C.C.T.	Control Mode
LED GU10 60° - 4W
HX-4F-GU10	220-240V	4 W	0.5	360lm	82	3000K	Dim option
HX-4F-GU10	220-240V	4 W	0.5	360lm	82	4000K	Dim option
HX-4F-GU10	220-240V	4 W	0.5	360lm	82	6500K	Dim option

Code	Input	Power	PF	Total Lumen	C.R.I	C.C.T.	Control Mode
LED GU10 60° - 5W
HX-5F-GU10	220-240V	5 W	0.5	450lm	82	3000K	Dim option
HX-5F-GU10	220-240V	5 W	0.5	450lm	82	4000K	Dim option
HX-5F-GU10	220-240V	5 W	0.5	450lm	82	6500K	Dim option

LED GU10 1-5W 60° | GU10

HX-XF-GU10 60° (X=1,2,3,4,5,6)
