SWORD | LED STREET LIGHT

BASIC INFORMATION:
LED Street Light GALLOP 50-200W
Input wires: 3x0.75mm² H05RN-F rubber cable
LED board: Aluminium
LED: SMD3030
Driver: Constant IC
Housing: Die-cast Aluminium body, ABS lens
Application: Road, Street, project lighting, etc.

Inquiry

TECHNICAL CHARACTERISTICS

Directive (LVD) -2014/35/EU
Directive (EMC)-2014/30/EU
Directive (RoHS)-2011/65/EU (EU)2015/863

Directive (EuP)-2009/125/EC
EN 60598-1:2015 +A1:2018
EN 60598- 2-1:1989
EN 62493:2015
EN 62471:2008
EN 55015:2013 +A1:2015
EN 61000-3-2:2014
EN 61000-3-3:2013
EN 61547:2009
EN 50581:2012

Code	Input	Power	PF	Lumen	C.R.I	C.C.T.	IP Grade	Surge
LED Street Light SWORD 50W
LSTL-S50-2101	85-265V	50 W	0.9	5000LM	80	3000K	IP65	4KV
LSTL-S50-2101	85-265V	50 W	0.9	5000LM	80	4000K	IP65	4KV
LSTL-S50-2101	85-265V	50 W	0.9	5000LM	80	6500K	IP65	4KV

Code	Input	Power	PF	Lumen	C.R.I	C.C.T.	IP Grade	Surge
LED Street Light SWORD 100W
LSTL-S100-2101	85-265V	50 W	0.9	10000LM	80	3000K	IP65	4KV
LSTL-S100-2101	85-265V	50 W	0.9	10000LM	80	4000K	IP65	4KV
LSTL-S100-2101	85-265V	50 W	0.9	10000LM	80	6500K	IP65	4KV

Code	Input	Power	PF	Lumen	C.R.I	C.C.T.	IP Grade	Surge
LED Street Light SWORD 150W
LSTL-S150-2101	85-265V	150 W	0.9	15000LM	80	3000K	IP65	4KV
LSTL-S150-2101	85-265V	150 W	0.9	15000LM	80	4000K	IP65	4KV
LSTL-S150-2101	85-265V	150 W	0.9	15000LM	80	6500K	IP65	4KV

Code	Input	Power	PF	Lumen	C.R.I	C.C.T.	IP Grade	Surge
LED Street Light SWORD 200W
LSTL-S200-2101	85-265V	200 W	0.9	20000LM	80	3000K	IP65	4KV
LSTL-S200-2101	85-265V	200 W	0.9	20000LM	80	4000K	IP65	4KV
LSTL-S200-2101	85-265V	200 W	0.9	20000LM	80	6500K	IP65	4KV
